FROST-LUX STANDARD safety / exit sign luminaire - frost-proof - polycarbonate - ceiling mounting

€ 6,16
Price incl. VAT
In 4 variations available
Please Choose Version...

Do you have any questions?
We would like to assist you!
verkauf@esska.de

Product Description
  • The frost-proof safety / escape sign luminaire FROST-LUX STANDARD is ideal for use in cold stores and outdoors as well as anywhere where the ambient temperature drops to -20 Â ° C.
  • This safety lamp is manufactured in accordance with the standards DIN EN 60598-2-22, EN 1838, EN 62034 and DIN VDE 0108.
Application
  • The housing and the cover or the cover hood are made of impact-resistant, break-proof polycarbonate. The pictograms are available as PET film or as self-adhesive PET film.
  • The luminaire is equipped with an automatic test function "AUTOTEST", signaling via three colored LEDs and a test button.
  • The low-energy safety luminaire has a permanent switch and can be easily attached to the wall or ceiling thanks to the "click mounting system". The power cable can be inserted flexibly.
  • Depending on the variant, the pictograms are glued to the cover or inserted into the cover.
  • The service life of the LEDs (SMD LEDs) has been tested to be at least 50,000 hours. The high-temperature NI-MH battery offers a long service life.
  • The manufacturer grants a 7-year guarantee on the lamp itself and a 5-year guarantee on the battery.
Technical Data
  • Housing material - polycarbonate, impact-resistant, break-proof
  • Material cover - polycarbonate, transparent, impact-resistant, break-proof
  • Material cover - polycarbonate, opal, impact-resistant, break-proof
  • Material pictogram - PET film, self-adhesive or PET film
  • Housing color - RAL 9003 (white)
  • Construction - wall or ceiling
  • Mains voltage - 230 V AC
  • Mains power - 1.5 W.
  • Degree of protection - IP 65
  • Protection class - II
  • Operating time - 3 hours
  • Battery - Ni-MH 4.8 V / 1.6 Ah
  • Luminous flux in emergency mode - 142 lm
  • Light source - 4 high-power LEDs
  • Viewing distance - 24 to 26 m
  • Ambient temperature - -20 to +40 Â ° C
show more...
show less...
The scope of delivery includes a standard set of information signs (emergency exit, escape route on the right, escape route left, escape route straight ahead) in accordance with DIN EN ISO 7010.
Versions: (4)
Narrow down your selection
Test function
emergency light
Area of application
Dimensions
Recognition distance
Network performance
Mains voltage
show all 4 implementations
Anzeigen als list Table
Item No.: 7678F561GD00
Type
Test functionPictogram "Escape route downwards left", PET film, TYPE D
emergency light
Area of application
Dimensions
Recognition distance
Network performance
Mains voltage
Product safety
Unfortunately, the manufacturer's data is not yet available. We will try to update the data as soon as possible.
€ 6,16
Price incl. VAT
available after order placement within 4 weeks
Item No.: 7678F561GE00
Type
Test functionPictogram "Escape route downwards to the right", PET film, TYPE E
emergency light
Area of application
Dimensions
Recognition distance
Network performance
Mains voltage
Product safety
Unfortunately, the manufacturer's data is not yet available. We will try to update the data as soon as possible.
€ 6,16
Price incl. VAT
Ex stock within 4 days deliverable
Item No.: 7678F561GF00
Type
Test function"Escape route upwards left" pictogram, PET film, TYPE F
emergency light
Area of application
Dimensions
Recognition distance
Network performance
Mains voltage
Product safety
Unfortunately, the manufacturer's data is not yet available. We will try to update the data as soon as possible.
€ 6,16
Price incl. VAT
Ex stock within 4 days deliverable
Item No.: 7678F561GG00
Type
Test function"Escape route upwards right" pictogram, PET film, TYPE G
emergency light
Area of application
Dimensions
Recognition distance
Network performance
Mains voltage
Product safety
Unfortunately, the manufacturer's data is not yet available. We will try to update the data as soon as possible.
€ 6,16
Price incl. VAT
Ex stock within 4 days deliverable
Product safety
Unfortunately, the manufacturer's data is not yet available. We will try to update the data as soon as possible.
