FROST-LUX STANDARD safety / escape sign luminaire - frost-proof - polycarbonate - wall / ceiling mounting
| € 6,16 |
| Price incl. VAT |
Do you have any questions?
We would like to assist you!
We would like to assist you!
Product Description
- The frost-proof safety / escape sign luminaire FROST-LUX STANDARD is ideal for use in cold stores and outdoors as well as anywhere where the ambient temperature drops to -20 Â ° C.
- This safety lamp is manufactured in accordance with the standards DIN EN 60598-2-22, EN 1838, EN 62034 and DIN VDE 0108.
- The housing and the cover or the cover hood are made of impact-resistant, break-proof polycarbonate. The pictograms are available as PET film or as self-adhesive PET film.
- The luminaire is equipped with an automatic test function "AUTOTEST", signaling via three colored LEDs and a test button.
- The low-energy safety luminaire has a permanent switch and can be easily attached to the wall or ceiling thanks to the "click mounting system". The power cable can be inserted flexibly.
- Depending on the variant, the pictograms are glued to the cover or inserted into the cover.
- The service life of the LEDs (SMD LEDs) has been tested to be at least 50,000 hours. The high-temperature NI-MH battery offers a long service life.
- The manufacturer grants a 7-year guarantee on the lamp itself and a 5-year guarantee on the battery.
- Housing material - polycarbonate, impact-resistant, break-proof
- Material cover - polycarbonate, transparent, impact-resistant, break-proof
- Material pictogram - PET film, self-adhesive
- Housing color - RAL 9003 (white)
- Construction - wall or ceiling
- Dimensions (LxWxH) - 329 x 144 x 78 mm
- Mains voltage - 230 V AC
- Mains power - 1.5 W.
- Degree of protection - IP 65
- Protection class - II
- Operating time - 3 hours
- Battery - Ni-MH 4.8 V / 1.6 Ah
- Luminous flux in emergency mode - 142 lm
- Light source - 4 high-power LEDs
- Viewing distance - 24 m
- Ambient temperature - -20 to +40 Â ° C
The scope of delivery includes a standard set of information signs (emergency exit, escape route on the right, escape route left, escape route straight ahead) in accordance with DIN EN ISO 7010.
Versions: (4)
Narrow down your selection
Test function
emergency light
Area of application
Dimensions
Recognition distance
Network performance
Mains voltage
Item No.: 7678F561FD00
Type
| Test function | Pictogram "Escape route downwards left", self-adhesive PET film, TYPE D |
| emergency light | |
| Area of application | |
| Dimensions | |
| Recognition distance | |
| Network performance | |
| Mains voltage |
| € 6,16 |
| Price incl. VAT |
Delivery time 2 - 4 working days
Item No.: 7678F561FE00
Type
| Test function | Pictogram "Escape route down to the right", self-adhesive PET film, TYPE E |
| emergency light | |
| Area of application | |
| Dimensions | |
| Recognition distance | |
| Network performance | |
| Mains voltage |
| € 6,16 |
| Price incl. VAT |
Delivery time 2 - 4 working days
Item No.: 7678F561FF00
Type
| Test function | "Escape route upwards left" pictogram, self-adhesive PET film, TYPE F |
| emergency light | |
| Area of application | |
| Dimensions | |
| Recognition distance | |
| Network performance | |
| Mains voltage |
| € 6,16 |
| Price incl. VAT |
Delivery time 2 - 4 working days
Item No.: 7678F561FG00
Type
| Test function | "Escape route upwards right" pictogram, self-adhesive PET film, TYPE G |
| emergency light | |
| Area of application | |
| Dimensions | |
| Recognition distance | |
| Network performance | |
| Mains voltage |
| € 6,16 |
| Price incl. VAT |
Delivery time 2 - 4 working days
